Glass Edge Polishing Wheel for Shaped Edging Machine

Product Details

Henan, China (Mainland)

BOSDI

GC1251020t41

Silicon Carbide

125mm (5'')

Cylinder

Surface/Creep-feed

Resin

Dense

Dry/Wet

125*10*20mm

Payment & Shipping Terms

Pieces

10

Detailed Product Description

architectureal glass coating deletion wheel film deletion wheel

Glass Edge Coating/Film Removal Wheel:

Why Edge Delete



Due to energy saving and environmental friendly, low-e coating glass becomes more important in architectural and building industries. Low-e coating is a very delicate thin film depositing on glass surface. Therefore, low-e glass is always insulated with another piece of glass. Low-e coating always faces in the inner side of double glazing. The space is either ordinary dry air or filled up with inert gas. The dry air or inert gas would not corrode the low-e coating. This protects low-e coating from corrosion.





The space between two pieces of glass is always separated by spacer bar. Spacer bar could be aluminum, steel, stainless steel, reinforced plastic or rubber. Due to its excellent moisture proof, butyl is chosen to be the adhesive to seal between spacer bar and glass. However, the adhesion between butyl and low-e coating does not perform well. Consequently, it is always required to remove the low-e coating around the edges of the glass. This process is known as low-e edge deletion. After low-e edges are deleted, glass edges are exposed. Butyl gets in direct contact with glass. This allows the adhesion in best performance.



architectureal glass coating deletion wheel film deletion wheel

Features:

1.    High fineness and excellent polishing;

2.    Sharpness and good self-sharpening;

3.    Strong intensity and safety in use.



Applications:

1.    Particular suitable for removing the edge film of vacuum glass;

2.    Be suit for polishing glass or the edge of organic glass;

3.    Be widely used in the field of glass.



Specifications:



Commodity

Item No.

Dimension

Speed (m/s)

PackagingPCS/CTN

mm

inch

GC1251020T41

125x10x20

5" x 2/5"x4/5”

35

200

GC1501020T41

150x10x20

6" x 2/5"x4/5”

35

200

GC1502076T41

150x20x76

6" x 4/5"x3”

35

200

GC2001076T41

200x10x76

8" x 2/5”x3"

35

100

GC2001276T41

200x12x76

8" x 2/5”x3"

35

100

GC2001376T41

200x13x76

8" x 2/5”x3"

35

100



 architectureal glass coating deletion wheel film deletion wheel
