Non Ferrous Products Grinding wheel with Powerful Backing Support
Grooving Grinding Wheel for Tempered Glass Non-ferrous Products
100*16mm flexible flap disc radial flap disc plastic backing
A/C 24#-46# depressed centre fiber net polishing and cutting disc
cup-shaped rail track grinding wheel with four threaded hole
WA60 105*1.5*16mm doube net cutting wheel for stainless steel
T41 Abrasive super thin straight cutting wheels, cutting disc
100*6*16 mm depressed center fiberglass reinforce grinding wheels
Zirconia-Alumina depressed center cutting and gringding wheels
fiberglass reinforce double net cutting wheel, cutting disc,
T41 fiber reinforce green cutt-off wheel for cutting and grooving
T42 black flexible grinding and cutting disc, gringding wheel
Red 4'' two nets thin cutting wheel, cutting disc, cut-off wheel
resin black cut-off wheel for metal, stainless steel, alloys.
metal cutting wheel with resin bonded, cutting disc, cut-off wheel
Henan, China (Mainland)
BOSDI
White Aluminum Oxide
100/102mm (4''), 115mm (4-1/2''), 125mm (5''), 150/155mm (6''), 175/180mm (7''), 225/230mm (9''), 250/254mm (10''), 300/305mm (12''), 350/356mm (14''), 400/406mm (16'')
36
Aluminum, Steel/Steel Alloys, Stainless
High Speed, Chop Saw, Stationary Saw, For Rail
cutting or grooving
green
glass fiber
resin
80m/s
Pieces
1000
USD 1.333 - 0.000
SHANGHAI
15DAYS
CARTON
Yes
1000000 / Year
T/T
Specifications:
Cutting and Grinding wheels：
The base of cutting and grinding wheels is abrasives, glass fiber mesh and resin bone. The wheels are intended for various materials, such as metal, steel, alloys, stainless steel, stone, brick, concrete, asphalt, etc.
The choice of the hardness
wheel hardness from D to Y total of 16 hardness range Relatively more hard steel material need more soft emery wheel grinding, the soft steel material needs the hard grinding wheel grinding. Non-ferrous metals, copper
Feature:
Cutting wheel
1. Less resistance offers shorter cutting times.
2. Less working piece waste and dust generation
3. Maximum cutting speed with minimal burr，excellent durability
4. Ease of operation, less vibration, suitable for all ferrous and non-ferrous materials.
Type: T41, T42, T27
According to abrasive grit:
|
Grit |
Application |
|
24#-40# |
Non-ferrous metals. Wood and plastic. |
|
60# |
Alloyed steels, stainless steels, and tempered steels. |
|
80# |
High temperature alloys, stainless and heat treated steel, High tensile non-ferrous metal. |
|
120#-320# |
Fine finish of all materials. |
According to abrasive material:
|
Abrasive |
Application |
|
Aluminum oxide |
Very good abrasive action and a high hardness grade, used for alloyed and unalloyed steels, structural steel, too steel. |
|
Zirconia Allumina |
High temperature alloys, stainless and heat treated steel. High tensile non-ferrous metal. |
|
Silicon Carbide |
Granite, marble, stone, plastics, fiberglass, non-ferrous, material, carbon steel and titanium and titanium alloys. |
Resin Abrasive
|
Commodity |
Application |
Dimension(mm) |
Abrasives |
Color |
Grit |
||
|
Dia. |
Th. |
In.Dia. |
|||||
|
T41 cutting wheel |
it is suitable for cutting and grooving metal, stainless steel, glass, stone, non-metal and soft metal |
100 105 115 125 150 180 230 305 355 405 |
1.0 1.2 1.5 1.6 1.9 2.0 2.5 3.0 3.2 |
10 16 22 22.2 25.4 |
A WA C |
Brown Green Black |
30#-- 280# |
|
T41 ultrathin Cutting wheel |
Composite material with A, WA and ZA, Double nets, wonderful plasticity, durable and solid. It is suit for stainless steel, alloys. |
75 100 115 125 150 180 230 250 300 350 405 |
1 1.2 1.8 1.9 2.0 |
10 16 22 25 |
A WA ZA |
Black |
30#-- 280# |
|
T42 cutting and grinding wheel |
Enhance the net with resin fiber and resin abrasive, do not burning working piece. |
100 115 125 150 180 230 |
2.5 3.0
|
16 22.2
|
A WA C |
Brown Green Black |
30#-- 280# |
|
T27 grinding wheel |
Glass fiber net, quality abrasives, Self-sharpening flaps. Grinding for all material |
100 115 125 150 180 230 |
4 6 |
16 22 |
A WA C |
Brown Black Green |
30#-- 280# |
|
T27 Flexible grinding wheel |
With plastic bond and reinforcement material and unique production line. Can grinding the corner and narrow part. |
100 115 127 180 |
3.0 |
16 22 |
AC WA GC |
40#- 320# |
30#-- 280# |
Cutting wheel package:
|
Dimension DXTXH (mm) |
Carton size (cm) |
Box Qty (PCS) |
weight (kg) |
|
100x1.2x16 |
36x24x25 |
800 |
20 |
|
115x1.4x22 |
47x25x14 |
500 |
13 |
|
125x1.4x22 |
47x27x15 |
500 |
17 |
|
150x1.6x22 |
36x32x17 |
400 |
18 |
|
180x1.5x22 |
42x20x20 |
200 |
18 |
|
230x1.9x22 |
25x24x25 |
100 |
18 |
|
100x2.5x16 |
32x22x24 |
400 |
18 |
|
115x2.5x22 |
38x26x14 |
200 |
18 |
|
125 x2.5x22 |
37x28x16 |
200 |
17 |
|
150 x2.5x22 |
35x32x18 |
200 |
26 |
|
180 x2.5x22 |
39x20x18 |
100 |
18 |
|
230 x2.5x22 |
51x21x27 |
100 |
26 |
|
250x2.5x25.4 |
26x26x19 |
50 |
16 |
|
300x2.5x25.4 |
32x9x32 |
25 |
9 |
|
350x2.5x25.4 |
37x9x37 |
25 |
15 |
|
400x3.2/4x25.4 |
42x10x42 |
25 |
22 |
We provide customized services; those data are just for reference!
Please contact for more information and quotation.
