Measures to Reduce the Grinding Surface Roughness of Workpieces

This article introduces some measures to reduce the surface roughness of workpieces.

From: www.iabrasive.comDate: 2015-10-09 08:27:16Views: 521

When grinding products, we can adopt the following measures to reduce the surface roughness of workpieces in addition to the precision of grinding machines:

Firstly, we should use diamond and cubic boron nitride and new corundum abrasives, and they all have excellent cutting performance.

Secondly, if the surface roughness of workpieces can not meet the requirements, it is suggested to use fine-grained grinding wheels.

For example, corundum grinding wheels with w20~w10 granularity resin binder and graphite filler, can achieve the roughness of the mirror surface grinding through reasonable finishing. And grinding wheels of 46#~80# with K hardness and ceramic binder, also can achieve Ra (0.025~0.012)μm roughness after adjusting machine tools and carefully balancing and dressing grinding wheels to get good micro-edge and clean coolant.

Thirdly, resin binder adding graphite filler

This kind of grinding wheel with binder and filler, not only has flexible polishing effect, but also good lubrication. Thus its grinding surface roughness can reach Ra (0.025~0.012) microns, suitable for fine grinding of workpieces. If we use graphite grinding wheel for grinding hard alloy, refractory steel and other hard processing materials, it will not only have high efficiency, low degree of fine grinding, but also can avoid the burns.

Fourthly, put the mixture of stearic acid and oil acid in the grinding wheels

Stearic acid and oil acid in the grinding wheels will have lubrication and polishing effect in the process of grinding. And it can also reduce the surface roughness of workpieces under the condition of wet milling.
