Power Electronics: Silicon Carbide Gains Traction

Research reported in the Japanese Journal of Applied Physics by researchers at Mitsubishi Electric Corporation describes the development of a new power module made from a SiC metal-oxide-semiconductor field-effect transistor and a SiC Schottky barrier dio

From: electroiq.comDate: 2015-10-09 07:33:17Views: 634

Research reported in the Japanese Journal of Applied Physics by researchers at Mitsubishi Electric Corporation describes the development of a new power module made from a SiC metal-oxide-semiconductor field-effect transistor and a SiC Schottky barrier diode. The team successfully trialed the module in a train traction inverter — a device used to convert the direct current from the power source to three-phase alternating current suitable for driving the propulsion motors — with promising results.

Power electronics: Silicon carbide gains traction

Next-generation power electronics capable of reducing energy consumption are in high demand, particularly in the transportation industries. A key way of saving energy in electronics is by reducing the losses inherent in switching processes and power conversion. Much attention is now being given to a compound form of silicon and carbon called silicon carbide (SiC) for electronic components, a material whose properties outperform conventional silicon in terms of thermal conductivity, loss reduction and the ability to withstand high voltages.

Satoshi Yamakawa and co-workers at Mitsubishi Electric Corporation have developed a new power module made from a SiC metal-oxide-semiconductor field-effect transistor (MOSFET) and a SiC Schottky barrier diode (SBD). The team successfully trialed the module in a train traction inverter – a device used to convert the direct current from the power source to three-phase alternating current suitable for driving the propulsion motors — with promising results.

For a power module in a traction inverter, low power loss, miniaturization, high voltage rating, and high temperature environmental resistance are required.

Yamakawa and his team prepared the SiC MOSFET for the power module by n-type doping the junction field-effect transistor region: this reduced on-resistance of the device at high temperatures. By combining the SiC MOSFET with a SiC SBD — a diode which allows for fast and efficient switching — the team created a power module for a traction inverter rated at 3.3kV/1500A.

A new traction inverter system equipped with their power module is stable, highly efficient and reduces switching losses by 55% compared with conventional silicon-based inverters.
