How to Deal With Oil-leakage Malfunction of Surface Grinder?

Oil-leakage malfunction of surface grinder is the headache of many users, but as long as they master the oil-leakage reasons and judgment methods of surface grinder, and propose the improvement measures, the problem will be solved.

Generally speaking, oil-leakage malfunction of surface grinder has the following main problems:

Firstly, oil-leakage of dust sheet metal on both ends of the workbench is generally caused by careless surface grinder assembly. The screws to fix dust sheet metal go through the guide rail ends, and oil come out from the guide rail directly. The solution is that the screws surface grinder should be wrapped tape before installation.

Secondly, the fuel control is adjusted largely., so we need to open the tank cover to adjust the oil valve switch by using a screwdriver. Please note the clockwise direction for down. Generally speaking, the adjustment of the oil control should be heading firstly into the clockwise direction to lock tight and then transfer back loose about a quarter; The oil grooves on the wear-resisting pieces of guide rail surface grinder are not good, which is too shallow or not in place, and oil can not overflow from the side, so it should be opened in place; Oil hole is blocked, and the oil is forced out of the guide rail. The oil hole plugging is commonly caused by too sticky or too dirty oil, which needs to replace oil or clean up the oil. If it is old surface grinder, it is generally caused by too dirty guide rail. It is ok to clean up or change the oil.

Thirdly, the problem is oil-leakage malfunction of lead screw. If it is a new surface grinder, it is generally caused that telescopic sheath of lead screw is not packed well, or the screws on two ends are not locked tightly and the sealant are not bonded well. If it is an old surface grinder, it will just replace the screw sheath, and make sealant again.

If there is something wrong with surface grinder, it must make sure to find the right reason, and problems will be solved.
