High Speed Machining Gray Iron Gearbox With SNEN0904ENS Solid Cbn Cutting Tool From Halnn Tools
1. Halnn Tools CBN Solid Cbn Cutting Tool Finish Milling Gearbox
Gearbox processing difficulties
(1) The shape is complicated, and most of them are thin-walled shells, and the workpiece has poor rigidity, which is difficult to clamp.
(2) The processing precision is high, the processing quality of ordinary machine tools is difficult to guarantee,and the production efficiency is difficult to improve;
The boring process is the key to the production of gearboxes. It is necessary to ensure the positional accuracy and machining accuracy requirements. In the mass production process, combined machine tools or machining centers are often used for production. The use of Halnn Tools super-hard BNK30 material boring can extend tool life and increase productivity。
2. BN-S300 CBN Solid Cbn Cutting Tool Cutting Conditions
|
Insert Grade |
Suited Materials |
Machining Type |
Typical Application |
|
BN-S300 |
Gray Cast Iron |
Roughing, Finishing |
,Brake Drum, Cast Iron Engine |
|
BNK30 |
Cast Gray Iron, Iron based alloy |
Finishing |
Brake Disc,Powder Metallurgy Parts,Valve seat ring, Engine Cylinder bore |
3.Pictures of Halnn Tools BN-S300 Solid Cbn Cutting Tool
4.Detailed Data of BN-S300 Solid Cbn Cutting Tool
|
Type |
Dimension |
Grades |
|||||
|
L(mm) |
φI.C(mm) |
S(mm) |
r(mm) |
BN-S300 |
BN-S30 |
BNK30 |
|
|
SNEN0904ENS |
9.525 |
9.525 |
4.76 |
0.8 |
● |
◎ |
◎ |
|
SNEN1204ENS |
12.7 |
12.7 |
4.76 |
1.2 |
● |
◎ |
◎ |
|
SNEN1207ENS |
12.7 |
12.7 |
7.94 |
1.2 |
● |
◎ |
◎ |
|
SNEN120712 |
12.7 |
12.7 |
7.94 |
1.2 |
● |
◎ |
◎ |
|
SNEN19T6ENS |
19.05 |
19.05 |
6.8 |
1.6 |
● |
◎ |
◎ |
5.Application Case
Application of Halnn Tools CBN tool in Gray Cast Iron Gearbox
Milling plane process: Halnn Tools Superhard CBN tool BN-S300 material can be milled at a cutting speed of 2000m/min, which is nearly 5 times higher than the limit cutting speed of the hard alloy, and the finish of the machined surface is guaranteed to be within Ra1.6.
6.Our service
Pre-Sales Service
l) Prompt reply and 24 hours online,professional team to provide best price and quality product.
l) Same testing support
l ) Every batch of products will be tested to ensure its quality.
After-sales Service
l) The real-time logistics information monitoring
l ) Any questions about the product can be consulted at any time.
l) Product with any problem can return.
7.FAQ
A: We are a manufacturer and wholesaler for diamond & CBN (cubic boron nitride) abrasives and tools.
A: Generally it is 3 -7 days.
A: Normally we do not offer free samples, we could offer the sample for testing, but shipping fee is to be paid by customer as a company policy!
